Installation products and flashings

The range of VELUX flashings and installation products make the professional installation of your roof
windows quick, simple and safe. All original VELUX installation products are compatible to ensure
that your roof window is weathertight and safe connected to the roof construction and has an
excellent finish on the inside.

  • Fit exact window dimensions and connect perfectly to your roofing material.

  • Pleated underfelt collar (type BFX) forms a tight seal between roofwindow and your felt underlay. The self-supporting drainage gutter ensures safe water drainage from above the window.

  • Insulation frame (type BDX), with flexible foam for a tight and secure fit to the roof construction.

  • Vapour barrier collar (type BBX), including assembly tool for a vapour- and airtight solution.

  • Prefabricated linings (type LSB/LSC/LSD) for easy and airtight inside completion. Includes vapour barrier collar (type BBX), a tool for a vapour- and airtight solution.

1 2  3  4  5  6  7
Original VELUX
Flashings
 Underfelt collar BFX
 Water drainage
gutter
 Insulation frame
BDX
 Vapour barrier
collar BBX
 Interior lining
LSB / LSC / LSD
 Lining frame
kit LSG
Fit exact window
dimensions and
connect perfectly
to your roofing material
 Pleated underfelt
collar forms a
tight seal between
roofwindow and
your felt underlay.
 Self-supporting
drainage gutter
ensures safe
water drainage
from above the
window.
 Insulation frame
with flexible foam for a tight and secure fit to the roof construction.
 Vapour barrier
collar, including assembly tool for a vapour- and airtight solution.
 Prefabricated linings
for easy and airtight inside completion. Includes vapour
barrier collar.
 Easy-to-assem­ble,
adjustable steel
frame for fast and
easy framing for
your on-site lining. Includes vapour
barrier collar.


Standard or recessed installation

VELUX New Generation roof windows offer two installation heights, standard or recessed.

The recessed installation provides a sleek, streamlined appearance, sitting 40 mm deeper in the roof structure, and provides architects with greater design flexibility.

For optimum insulation effect, the VELUX Group recommends recessed installations. When installed with the appropriate VELUX insulation collar, recessed installations results in saving more energy.

Roof window installed on a pitched roof
A1: Standard installation
Roof window installed recessed on a pitched roof
A2: Recessed installation

Tile flashings

Flashings on a window installed on a roof

EDW/EBW/EKW

  • For standard installation of roof windows in flat or profiled roofing material up to 120mm in profile
  • Also for interlocking slate, thatch and profiled sheeting
  • Suitable for 15°-90° roof pitches
Flashings on a window installed on a roof

EDP/EBP/EKP

  • For standard installation of roof windows in plain tiles (max length 300mm)
  • Maximum tile thickness of 14mm
  • Suitable for 25°-90° roof pitches
Flashings on a window installed on a roof

EDJ/EKJ

  • For recessed installation of roof windows into flat or profiled roofing material up to 90mm in profile
  • EDJ 2000 version includes BDX insulation collar as standard
  • Suitable for 20°-90°

Slate flashings

Flashings on a window installed on a roof

EDL/EBL/EKL

  • For standard installation of roof windows into slate up to 8mm thick
  • Not for interlocking slate
  • Suitable for 15°-90° roof pitches
Flashings on a window installed on a roof

EDN/EKN

  • For recessed installation into slate up to 8mm thick
  • EDN 2000 includes BDX insulation collar as standard
  • Not for interlocking slate
  • Suitable for 20°-90° roof pitches

Extra insulation and protection

Optimise your new roof window to ensure an energy-efficient and durable installation. You can choose the frame insulation product BDX, which ensures proper insulation between the roof construction and the window frame, and the pleated underfelt collar BFX, which ensures a flexible and tight connection between the underfelt and the window frame. The drainage gutter ensures that water from the underfelt above can drain away from the window.

Craftsman installing a window frame on a pitched roof
B1: Insulation frame.
Craftsman installing a window on a pitched roof
B2: Drainage gutter.
B3: Pleated underfelt collar.

Excellent interior finish

Use VELUX linings to optimise the finish in your room. We recommend the pre-fabricated VELUX linings LSB/LSC/LSD with sharp lines to match contemporary styles. The linings are made in water- and moisture-repellent materials with a white finished surface treatment. The unique design creates space for extra insulation material to prevent thermal bridges. Alternatively, VELUX kit for lining LSG forms a perfect structure for shaping your own plasterboard lining.

The unique design creates space for extra insulation material to prevent thermal bridges. Both VELUX linings and VELUX kit for lining are delivered with VELUX vapour barrier collar BBX, which is 100% vapour-tight and prevents condensation.

Window with explanatory installment guides
C1: Lining frame LSG.
C2: Vapour barrier collar BBX.
Window almost installed
Interior lining LSB / LSC / LSD.
Newly installed window
Excellent and perfect interior finish.
